Wide-spectrum, co-focusing system, Toshiba HD imaging capture, accurately position the aim and Intelligent analyze and high speed processing.;
Espcially good at identifying and sorting light yellow, tiny spot, micro color difference etc;
Multi-function,multi-purpose,widely used for rice,millet,sesame etc;
Cold LED light source, long life span and maintenance free;
Combined with color sorting, shape sorting and size sorting;
High and specification ensures high stability,with high sorting accuracy, small carry over and low energy consumption;
full color technology with wide spectrum, intelligent system, self-learning function, easy operation;
| Model | RC1 | RC2 | RC3 | RC5 | RC7 | RC8 | RC10 | RC12 |
| Executing Unit | 64 | 128 | 192 | 320 | 448 | 512 | 640 | 768 |
| Throughout(t/h) | 0.5~3 | 1~4 | 2~6 | 5~10 | 9~17 | 11~20 | 12~22 | 13~25 |
| Voltage(V) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) | 110~220V (50~60Hz) |
| Power(kW) | 1 | 1.4 | 1.8 | 2.6 | 3.5 | 4 | 5 | 6 |
| Weight(kg) | 210 | 350 | 600 | 880 | 1150 | 1250 | 1400 | 1650 |
| Dimension(L*W*H/mm) | 960*1630*2050 | 1340*1630*2050 | 1610*1630*2050 | 2225*1630*2050 | 2980*1630*2050 | 3068*1630*2056 | 2116*2967*1985 | 2595*2967*1985 |
| Sorting accuracy(%) | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 |
| Rejection rate | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 | ≥8:1 | ≥8:1 | ≥8:1 |
| Air consumption(L/min) | 400~800 | 600~1000 | 800~1600 | 1300~2200 | 1800~3600 | 2200~4000 | 2400~4500 | 2700~5000 |
| Notes | We can product models from 1-8chutes,and models with 10,12 and 14 chutes. | |||||||
Note:Subject to different impurities of raw materials,parameters listed in above table will change to some extent
Sorting Examples:
