Full Color RGB rice Color Sorter

  • products detail
  • Product Parameters

  • Features of RGB rice Color Sorter

    1. Japanse top Chromatic CCD sensor,High resolution spectial camera with pixile 5400 elements;Cold LED light source,long life span and maintenance free;

    2. High reliability ejectors,key parts from Japan,life time over 10 billion times;

    3. Super rejection for tiny bad spot and micro color difference;

    Sorting Examples


    Model and Specification

    ModelRC1RC2RC3RC5RC7RC8RC10RC12
    Executing Unit64128192320448512640768
    Throughout(t/h)0.5~31~42~65~109~1711~2012~2213~25
    Voltage(V)110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)
    Power(kW)11.41.82.63.5456
    Weight(kg)2103506008801150125014001650
    Dimension(L*W*H/mm)960*1630*20501340*1630*20501610*1630*20502225*1630*20502980*1630*20503068*1630*20562116*2967*19852595*2967*1985
    Sorting accuracy(%)≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99
    Rejection rate≥10:1≥10:1≥10:1≥10:1≥10:1≥8:1≥8:1≥8:1
    Air consumption(L/min)400~800600~1000800~16001300~22001800~36002200~40002400~45002700~5000
    NotesWe can product models from 1-8chutes,and models with 10,12 and 14 chutes.


    Features of RGB rice Color Sorter

    1. Japanse top Chromatic CCD sensor,High resolution spectial camera with pixile 5400 elements;Cold LED light source,long life span and maintenance free;

    2. High reliability ejectors,key parts from Japan,life time over 10 billion times;

    3. Super rejection for tiny bad spot and micro color difference;

    Sorting Examples


    Model and Specification

    ModelRC1RC2RC3RC5RC7RC8RC10RC12
    Executing Unit64128192320448512640768
    Throughout(t/h)0.5~31~42~65~109~1711~2012~2213~25
    Voltage(V)110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)    		110~220V
    (50~60Hz)
    Power(kW)11.41.82.63.5456
    Weight(kg)2103506008801150125014001650
    Dimension(L*W*H/mm)960*1630*20501340*1630*20501610*1630*20502225*1630*20502980*1630*20503068*1630*20562116*2967*19852595*2967*1985
    Sorting accuracy(%)≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99≥99.99
    Rejection rate≥10:1≥10:1≥10:1≥10:1≥10:1≥8:1≥8:1≥8:1
    Air consumption(L/min)400~800600~1000800~16001300~22001800~36002200~40002400~45002700~5000
    NotesWe can product models from 1-8chutes,and models with 10,12 and 14 chutes.


  • Model：
    Seven Chutes Full Color RGB CCD Color Sorter
    Executing Unit：
    320
    Throughout(t/h)：
    5~10
    Voltage(V)：
    110~250V (50~60Hz)
    Power(kW)：
    2.6
    Weight(kg)：
    880
    Dimension(L*W*H/mm)：
    2225*1630*2050
    Sorting accuracy(%)：
    ≥99.99
    Rejection rate：
    ≥10:1
    Air consumption(L/min)：
    1300~2200
