Professional industrial wide view camera lens,Japanese top chromatic CCD sensor,high reliability and long life LED light source,original Italian Matrix or Chinese high reliability ejectors,American super speed FPGA processor;
Color sorting,shape sorting and material sorting functions combined;
Unique optical design,leading at sorting light colors in the industry;
Intellignent system,self-learning function,easy operation;
Reduced electric and compressed air consumption;
Realtech has professional sorting technology,consistent product quality;
New 8-inches touch screen,realizes faster and easier operation;
Model | MT1 | MT2 | MT3 | MT4 | MT5 | MT6 | MT7 |
Executing Unit | 64 | 128 | 192 | 256 | 320 | 384 | 448 |
Throughout(t/h) | 0.5~1.4 | 0.5~2.5 | 1.5~5 | 2~6 | 3~8 | 4~10 | 5~12 |
Voltage(V) | 110/220V-50/60HZ | 110/220V-50/60HZ | 110/220V-50/60HZ | 110/220V-50/60HZ | 110/220V-50/60HZ | 110/220V-50/60HZ | 110/220V-50/60HZ |
Power(kW) | 1 | 1.4 | 1.8 | 2.2 | 2.6 | 3 | 3.5 |
Weight(kg) | 210 | 350 | 600 | 750 | 880 | 1050 | 1150 |
Dimension(L*W*H/mm) | 960*1630*2050 | 1340*1630*2050 | 1610*1630*2050 | 1965*1630*2050 | 2225*1630*2050 | 2595*1630*2050 | 2980*1630*2050 |
Sorting accuracy(%) | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 |
Rejection rate | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 |
Air consumption(L/min) | 400~800 | 600~1000 | 800~1600 | 1000~1800 | 1300~2200 | 1500~3000 | 1800~3600 |
Note:Subject to different impurities of raw materials,parameters listed in above table will change to some extent
