Features of rice color sorter:
1.Wide-spectrum, co-focusing system, Toshiba HD imaging capture, accurately position the aim and Intelligent analyze and high speed processing.;
2.Espcially good at identifying and sorting light yellow, tiny spot, micro color difference etc;
3.Multi-function,multi-purpose,widely used for rice,millet,sesame etc;
4.Cold LED light source, long life span and maintenance free;
5.Combined with color sorting, shape sorting and size sorting;
6. High and specification ensures high stability,with high sorting accuracy, small carry over and low energy consumption;
7. Full color technology with wide spectrum, intelligent system, self-learning function, easy operation;
| Executing Unit | 6SXM-64 |
| Throughout(t/h) | 0.8 |
| Voltage(V) | 110/220V-50/60HZ |
| Power(kW) | 0.8 |
| Weight(kg) | 230 |
| Dimension(L*W*H/mm) | 795*1527*1474 |
| Sorting accuracy(%) | ≥99.9 |
| Rejection rate | ≥50:1 |
| Air consumption(L/min) | ≤120 |
Note:Subject to different impurities of raw materials,parameters listed in above table will change to some extent
Technical advantages:
Camera system:
Biomimetric recognization cameras of Industrail level,suitable for all kinds of different materials;Original imported sensor with pixle 5400 elements,line frequency at 10000 frames/second;LVDS communication effectively enhanced Common mode rejection ratio,and super reliability;Internet communication technology with high speed image acquisition function;images of material visable at operation interface.
Optical system:
All new customized industrial camera lens,higher sharpness and brightness,wider spectrum,large DOF and lower distortion,fully enhanced resolution;Wide spectrum;high reliability and steady temperature LED lighting system configuration,light auto-adaptation technically following the environmental change,massively increased detecting scope with consistency and continuity.
Electric system:
All electric components are international famous brands such as Schneider,SMC,MeanWell et which are of good safety and reliability.
Operation system:
Linux high reliability operation system,easy and professional integration,flexible configuration;Visual analysis technology,remote control access;big data cloud technology analysis.
Power supply system:
Wide range voltage,All DC power and APFC power supply,effectively restrain power harmonic,high safety and reliability.
Feeding system:
Productive,high voltage DC PWM control feeding system,maintain steady capacity adjustment;Special thickness craft processed chutes,greately reduced the friction coefficient,material flow smoothly and bigger capacity.
Ejection system:
Ejectors of ultralow remanence material,super conducting magnetic technology,key parts optized from Japan,high frequency of switching;high and low voltage and PWM control driving technology;powerful central point identifying technology,accurate shooting,and low air consumption.
Dust removal system:
Intelligent dust removal system,automatic sensor cleaning,more reliable;air curtain system and a unique combination of ventilation system to ensure camera is recognized without interference,a substantial increase in effective production.
Sorting Material:
